Integrating NetBox With Cisco Catalyst Center and Ansible

In this blog post I will demonstrate a simple NetBox integration that enables Ansible to automate devices managed by a Cisco Catalyst Center Controller. The solution covered here could easily be adapted to work with other controller based networks, such as Meraki and ACI.

Use Case

• Multiple Cisco Catalyst Center controllers managing devices in different regions
• You need to run automation tools targeting devices regardless of which CCC controller they are managed by.

Subscribe to our newsletter for more tutorials like these!

NetBox, Cisco Catalyst Center and Ansible Integration Overview

The four main elements of the integration are as follows:

1 – NetBox Custom Fields

The NetBox data model is extended by adding two Custom Fields to the devices model. Custom Field 1 is called cisco_catalyst_center, and is a Selection type field that maps to the hostname of the Cisco Catalyst Center controller:

The Custom Field makes use of a Choice Set called Cisco Catalyst Center Hosts which is a drop-down menu of available Cisco Catalyst Center hosts:

Custom Field 2 is called ccc_device_id, and is a Text type field that maps to the device UUID in the Cisco Catalyst Center controller:

2 – Devices Created in NetBox

Devices managed by the Cisco Catalyst Center are manually added to NetBox and the device data includes the custom field values for  cisco_catalyst_center and ccc_device_id:

3 – NetBox Dynamic Inventory for Ansible

The NetBox Inventory Plugin for Ansible is used to dynamically generate the inventory from NetBox to be used in the Ansible playbook:

# ansible.cfg

[defaults]
inventory = ./netbox_inv.yml

# netbox_inv.yml

plugin: netbox.netbox.nb_inventory
validate_certs: False
group_by:
 - device_roles
 - sites

4 – Ansible Playbooks

The Ansible playbooks target hosts based on the device_roles as defined in NetBox and pulled from the dynamic inventory. They contain a set_facts task to map the values of the ccc_device_id and cisco_catalyst_center custom fields to the devices, so they can be used in later tasks per inventory device:

---
- name: Get Device Details From Cisco Catalyst Center
  hosts: device_roles_distribution, device_roles_access

tasks:
    - name: Set Custom Fields as Facts for Cisco Catalyst Center host and Device UUID
    set_fact:
        cisco_catalyst_center: "{{ hostvars[inventory_hostname].custom_fields['cisco_catalyst_center'] }}"
        ccc_device_id: "{{ hostvars[inventory_hostname].custom_fields['ccc_device_id'] }}"

- name: Get Device Details
  uri:
    url: "https://{{ cisco_catalyst_center }}/dna/intent/api/v1/network-device/{{ ccc_device_id }}"
    method: GET
    return_content: yes
    validate_certs: no
    headers:
      Content-Type: "application/json"
      x-auth-token: "{{ login_response.json['Token'] }}"
  register: device_details
  delegate_to: localhost

So, I hope that this has been a useful overview of how to build a simple NetBox integration that enables Ansible to automate devices managed by a Cisco Catalyst Center Controller. If you’d like try this yourself then you can find full instructions and all the code in the accompanying Git Repository.
