MikroTik hEX S
The MikroTik hEX S (RB760iGS) is a infrastructure device from MikroTik. It features 7 network interfaces. The NDX catalog provides enrichment data across 7 categories including lifecycle, thermal, environmental, operational.
Last verified: April 4, 2026
Key Facts
| Manufacturer | MikroTik |
|---|---|
| Model | hEX S |
| Part Number | RB760iGS |
| Type | Device Type |
| Form Factor | 0U, half-depth |
| Airflow | passive |
| Weight | 350 g |
| Interfaces | 7 ports |
| Source | Community DTL |
| Enrichment | 7 categories available |
Specifications
Interfaces (7)
| Name | Type | Mgmt Only | Label |
|---|---|---|---|
| ether1 | 1000base-t | 1 | |
| ether2 | 1000base-t | 2 | |
| ether3 | 1000base-t | 3 | |
| ether4 | 1000base-t | 4 | |
| ether5 | 1000base-t | 5 | |
| sfp1 | 1000base-x-sfp | SFP | |
| usb | lte |
Power Ports (1)
| Name | Type | Max Draw (W) | Allocated (W) |
|---|---|---|---|
| DC | dc-terminal | 24 | 6 |
Module Bays (1)
| Name | Position | Label |
|---|---|---|
| microSD/microSDHC/microSDXC | microSD |
Data Sources & Provenance
| Field | Type | Confidence | Source |
|---|---|---|---|
| environmental.max_operating_temp_c | vendor product page | medium-high | mikrotik.com |
| thermal.cooling_type | vendor product page | medium-high | mikrotik.com |
| lifecycle.ga_date | vendor product page | medium-high | mikrotik.com |
| operational.max_power_draw_watts | vendor product page | medium-high | mikrotik.com |
| environmental.min_operating_temp_c | vendor datasheet | high | mikrotik.com |
| environmental.operating_humidity_min | vendor datasheet | high | mikrotik.com |
| environmental.operating_humidity_max | vendor datasheet | high | mikrotik.com |
| environmental.operating_altitude_m | vendor datasheet | high | mikrotik.com |
| snmp.versions | vendor documentation | high | mikrotik.com |
| snmp.vendor_oid_prefix | third party | high | www.iana.org |
| platform.nos | vendor product page | high | mikrotik.com |
| platform.api_types | heuristic | medium | derived from extension blocks and cli_protocol |
Frequently Asked Questions
What is the MikroTik hEX S?
The MikroTik hEX S (RB760iGS) is a infrastructure device from MikroTik. It features 7 network interfaces. The NDX catalog provides enrichment data across 7 categories including lifecycle, thermal, environmental, operational.
What is the form factor of the MikroTik hEX S?
The MikroTik hEX S is a non-rackable device (0U).
How many ports does the MikroTik hEX S have?
The MikroTik hEX S has 7 network interfaces: 5x 1000base-t, 1x 1000base-x-sfp, 1x lte.
What are the power requirements for the MikroTik hEX S?
The MikroTik hEX S has 1 power port (dc-terminal). Maximum power draw is 24W.
Is the MikroTik hEX S still supported?
Lifecycle data is available for the MikroTik hEX S in the NDX catalog. Access full lifecycle dates including general availability, end-of-sale, and end-of-support through NetBox Cloud or Enterprise.
What operational data is available for the MikroTik hEX S?
The NDX catalog includes enrichment data for the MikroTik hEX S in the following categories: lifecycle, thermal, environmental, operational, platform, snmp, imagery. Full enrichment values are available through NetBox Cloud or Enterprise.
How do I add the MikroTik hEX S to NetBox?
You can import the MikroTik hEX S directly into NetBox via the NDX features available in NetBox Cloud and NetBox Enterprise. NetBox Community users may download the YAML type definition and import it manually.
Where does the MikroTik hEX S data come from?
The MikroTik hEX S device type definition originates from the NetBox Community Device Type Library and has been enriched with operational metadata by NetBox Labs.
Related Devices from MikroTik
Last verified April 4, 2026.
Elevation
Enrichment Availability
| Category | Available |
|---|---|
| Lifecycle | |
| Thermal | |
| Environmental | |
| Operational | |
| Platform | |
| SNMP | |
| gNMI | |
| NETCONF | |
| Redfish | |
| Modbus | |
| Imagery |
Access full enrichment data with NetBox Cloud or Enterprise.
