Lenovo System x3650 M5
The Lenovo System x3650 M5 (8871) is a 2U infrastructure device from Lenovo. It features 5 network interfaces. The NDX catalog provides enrichment data across 6 categories including lifecycle, thermal, environmental, operational.
Last verified: April 2, 2026
Key Facts
| Manufacturer | Lenovo |
|---|---|
| Model | System x3650 M5 |
| Part Number | 8871 |
| Type | Device Type |
| Form Factor | 2U, full-depth |
| Airflow | front-to-rear |
| Weight | 19 kg |
| Interfaces | 5 ports |
| Source | Community DTL |
| Enrichment | 6 categories available |
Specifications
Interfaces (5)
| Name | Type | Mgmt Only | Label |
|---|---|---|---|
| Ethernet 1 | 1000base-t | ||
| Ethernet 2 | 1000base-t | ||
| Ethernet 3 | 1000base-t | ||
| Ethernet 4 | 1000base-t | ||
| IMM | 100base-tx | true |
Module Bays (11)
| Name | Position | Label |
|---|---|---|
| PSU 1 | 1 | |
| PSU 2 | 2 | |
| PCIe slot 1 - FH | PCIe-1 | 1 |
| PCIe slot 2 - FH | PCIe-2 | 2 |
| PCIe slot 3 or ML2 - FH | PCIe-3 | 3 |
| PCIe slot 4 - LP | PCIe-4 | 4 |
| PCIe slot 5 - LP | PCIe-5 | 5 |
| PCIe slot 6 - FH | PCIe-6 | 6 |
| PCIe slot 7 - FH | PCIe-7 | 7 |
| PCIe slot 8 - FH | PCIe-8 | 8 |
| Mezzanine LOM (ML2) | PCIe-8 | LOM |
Data Sources & Provenance
| Field | Type | Confidence | Source |
|---|---|---|---|
| thermal.tdp_watts | vendor datasheet | high | lenovopress.lenovo.com |
| environmental.max_operating_temp_c | vendor datasheet | high | lenovopress.lenovo.com |
| lifecycle.ga_date | vendor product page | medium-high | lenovopress.lenovo.com |
| lifecycle.eol_announced | vendor product page | medium-high | lenovopress.lenovo.com |
| lifecycle.eos_date | vendor product page | medium-high | lenovopress.lenovo.com |
| lifecycle.last_support_date | vendor datasheet | high | lenovopress.lenovo.com |
| operational.max_power_draw_watts | vendor datasheet | high | lenovopress.lenovo.com |
| operational.typical_power_draw_watts | vendor datasheet | high | lenovopress.lenovo.com |
| thermal.cooling_type | heuristic | low | ndx-pipeline-classification |
| environmental.min_operating_temp_c | vendor product page | high | lenovopress.lenovo.com |
| environmental.operating_humidity_min | vendor product page | high | lenovopress.lenovo.com |
| environmental.operating_humidity_max | vendor product page | high | lenovopress.lenovo.com |
| environmental.operating_altitude_m | vendor product page | high | lenovopress.lenovo.com |
| snmp.versions | vendor documentation | high | pubs.lenovo.com |
| snmp.vendor_oid_prefix | third party | high | www.iana.org |
| ipmi.ipmi_version | vendor documentation | high | pubs.lenovo.com |
Frequently Asked Questions
What is the Lenovo System x3650 M5?
The Lenovo System x3650 M5 (8871) is a 2U infrastructure device from Lenovo. It features 5 network interfaces. The NDX catalog provides enrichment data across 6 categories including lifecycle, thermal, environmental, operational.
What is the form factor of the Lenovo System x3650 M5?
The Lenovo System x3650 M5 is a 2U full-depth device with front-to-rear airflow. It weighs 19 kg.
How many ports does the Lenovo System x3650 M5 have?
The Lenovo System x3650 M5 has 5 network interfaces: 4x 1000base-t, 1x 100base-tx.
Is the Lenovo System x3650 M5 still supported?
Lifecycle data is available for the Lenovo System x3650 M5 in the NDX catalog. Access full lifecycle dates including general availability, end-of-sale, and end-of-support through NetBox Cloud or Enterprise.
What operational data is available for the Lenovo System x3650 M5?
The NDX catalog includes enrichment data for the Lenovo System x3650 M5 in the following categories: lifecycle, thermal, environmental, operational, snmp, imagery. Full enrichment values are available through NetBox Cloud or Enterprise.
How do I add the Lenovo System x3650 M5 to NetBox?
You can import the Lenovo System x3650 M5 directly into NetBox via the NDX features available in NetBox Cloud and NetBox Enterprise. NetBox Community users may download the YAML type definition and import it manually.
Where does the Lenovo System x3650 M5 data come from?
The Lenovo System x3650 M5 device type definition originates from the NetBox Community Device Type Library and has been enriched with operational metadata by NetBox Labs.
Related Devices from Lenovo
Last verified April 2, 2026.
Elevation
Enrichment Availability
| Category | Available |
|---|---|
| Lifecycle | |
| Thermal | |
| Environmental | |
| Operational | |
| Platform | |
| SNMP | |
| gNMI | |
| NETCONF | |
| Redfish | |
| Modbus | |
| Imagery |
Access full enrichment data with NetBox Cloud or Enterprise.
