Juniper QFX5120-48Y-DC-AFO2
The Juniper QFX5120-48Y-DC-AFO2 is a 1U infrastructure device from Juniper Networks. It features 57 network interfaces. The NDX catalog provides enrichment data across 7 categories including lifecycle, thermal, environmental, platform.
Last verified: April 4, 2026
Key Facts
| Manufacturer | Juniper Networks |
|---|---|
| Model | QFX5120-48Y-DC-AFO2 |
| Part Number | QFX5120-48Y-DC-AFO2 |
| Type | Device Type |
| Form Factor | 1U, full-depth |
| Airflow | front-to-rear |
| Weight | 23.7 lb |
| Interfaces | 57 ports |
| Source | Community DTL |
| Enrichment | 7 categories available |
Specifications
Interfaces (57)
| Name | Type | Mgmt Only | Label |
|---|---|---|---|
| fxp0 | 1000base-t | true | |
| et-0/0/0 | 25gbase-x-sfp28 | ||
| et-0/0/1 | 25gbase-x-sfp28 | ||
| et-0/0/2 | 25gbase-x-sfp28 | ||
| et-0/0/3 | 25gbase-x-sfp28 | ||
| et-0/0/4 | 25gbase-x-sfp28 | ||
| et-0/0/5 | 25gbase-x-sfp28 | ||
| et-0/0/6 | 25gbase-x-sfp28 | ||
| et-0/0/7 | 25gbase-x-sfp28 | ||
| et-0/0/8 | 25gbase-x-sfp28 | ||
| et-0/0/9 | 25gbase-x-sfp28 | ||
| et-0/0/10 | 25gbase-x-sfp28 | ||
| et-0/0/11 | 25gbase-x-sfp28 | ||
| et-0/0/12 | 25gbase-x-sfp28 | ||
| et-0/0/13 | 25gbase-x-sfp28 | ||
| et-0/0/14 | 25gbase-x-sfp28 | ||
| et-0/0/15 | 25gbase-x-sfp28 | ||
| et-0/0/16 | 25gbase-x-sfp28 | ||
| et-0/0/17 | 25gbase-x-sfp28 | ||
| et-0/0/18 | 25gbase-x-sfp28 | ||
| et-0/0/19 | 25gbase-x-sfp28 | ||
| et-0/0/20 | 25gbase-x-sfp28 | ||
| et-0/0/21 | 25gbase-x-sfp28 | ||
| et-0/0/22 | 25gbase-x-sfp28 | ||
| et-0/0/23 | 25gbase-x-sfp28 | ||
| et-0/0/24 | 25gbase-x-sfp28 | ||
| et-0/0/25 | 25gbase-x-sfp28 | ||
| et-0/0/26 | 25gbase-x-sfp28 | ||
| et-0/0/27 | 25gbase-x-sfp28 | ||
| et-0/0/28 | 25gbase-x-sfp28 | ||
| et-0/0/29 | 25gbase-x-sfp28 | ||
| et-0/0/30 | 25gbase-x-sfp28 | ||
| et-0/0/31 | 25gbase-x-sfp28 | ||
| et-0/0/32 | 25gbase-x-sfp28 | ||
| et-0/0/33 | 25gbase-x-sfp28 | ||
| et-0/0/34 | 25gbase-x-sfp28 | ||
| et-0/0/35 | 25gbase-x-sfp28 | ||
| et-0/0/36 | 25gbase-x-sfp28 | ||
| et-0/0/37 | 25gbase-x-sfp28 | ||
| et-0/0/38 | 25gbase-x-sfp28 | ||
| et-0/0/39 | 25gbase-x-sfp28 | ||
| et-0/0/40 | 25gbase-x-sfp28 | ||
| et-0/0/41 | 25gbase-x-sfp28 | ||
| et-0/0/42 | 25gbase-x-sfp28 | ||
| et-0/0/43 | 25gbase-x-sfp28 | ||
| et-0/0/44 | 25gbase-x-sfp28 | ||
| et-0/0/45 | 25gbase-x-sfp28 | ||
| et-0/0/46 | 25gbase-x-sfp28 | ||
| et-0/0/47 | 25gbase-x-sfp28 | ||
| et-0/0/48 | 100gbase-x-qsfp28 | ||
| et-0/0/49 | 100gbase-x-qsfp28 | ||
| et-0/0/50 | 100gbase-x-qsfp28 | ||
| et-0/0/51 | 100gbase-x-qsfp28 | ||
| et-0/0/52 | 100gbase-x-qsfp28 | ||
| et-0/0/53 | 100gbase-x-qsfp28 | ||
| et-0/0/54 | 100gbase-x-qsfp28 | ||
| et-0/0/55 | 100gbase-x-qsfp28 |
Console Ports (1)
| Name | Type |
|---|---|
| Console | rj-45 |
Module Bays (2)
| Name | Position | Label |
|---|---|---|
| PSU 0 | 0 | |
| PSU 1 | 1 |
Data Sources & Provenance
| Field | Type | Confidence | Source |
|---|---|---|---|
| lifecycle.ga_date | vendor product page | medium-high | www.juniper.net |
| environmental.max_operating_temp_c | vendor datasheet | high | www.juniper.net |
| thermal.cooling_type | vendor datasheet | high | www.juniper.net |
| environmental.min_operating_temp_c | vendor datasheet | high | www.juniper.net |
| environmental.operating_humidity_min | vendor datasheet | high | www.juniper.net |
| environmental.operating_humidity_max | vendor datasheet | high | www.juniper.net |
| environmental.operating_altitude_m | vendor datasheet | high | www.juniper.net |
| platform.nos | vendor product page | high | www.juniper.net |
| platform.api_types | heuristic | medium | derived from extension blocks and cli_protocol |
| snmp.vendor_oid_prefix | vendor documentation | high | www.juniper.net |
| netconf.netconf_version | vendor documentation | high | www.juniper.net |
Frequently Asked Questions
What is the Juniper QFX5120-48Y-DC-AFO2?
The Juniper QFX5120-48Y-DC-AFO2 is a 1U infrastructure device from Juniper Networks. It features 57 network interfaces. The NDX catalog provides enrichment data across 7 categories including lifecycle, thermal, environmental, platform.
What is the form factor of the Juniper QFX5120-48Y-DC-AFO2?
The Juniper QFX5120-48Y-DC-AFO2 is a 1U full-depth device with front-to-rear airflow. It weighs 23.7 lb.
How many ports does the Juniper QFX5120-48Y-DC-AFO2 have?
The Juniper QFX5120-48Y-DC-AFO2 has 57 network interfaces: 48x 25gbase-x-sfp28, 8x 100gbase-x-qsfp28, 1x 1000base-t.
Is the Juniper QFX5120-48Y-DC-AFO2 still supported?
Lifecycle data is available for the Juniper QFX5120-48Y-DC-AFO2 in the NDX catalog. Access full lifecycle dates including general availability, end-of-sale, and end-of-support through NetBox Cloud or Enterprise.
What operational data is available for the Juniper QFX5120-48Y-DC-AFO2?
The NDX catalog includes enrichment data for the Juniper QFX5120-48Y-DC-AFO2 in the following categories: lifecycle, thermal, environmental, platform, snmp, netconf, imagery. Full enrichment values are available through NetBox Cloud or Enterprise.
How do I add the Juniper QFX5120-48Y-DC-AFO2 to NetBox?
You can import the Juniper QFX5120-48Y-DC-AFO2 directly into NetBox via the NDX features available in NetBox Cloud and NetBox Enterprise. NetBox Community users may download the YAML type definition and import it manually.
Where does the Juniper QFX5120-48Y-DC-AFO2 data come from?
The Juniper QFX5120-48Y-DC-AFO2 device type definition originates from the NetBox Community Device Type Library and has been enriched with operational metadata by NetBox Labs.
