Juniper EX4000-12MP
The Juniper EX4000-12MP is a 1U infrastructure device from Juniper Networks. It features 17 network interfaces. The NDX catalog provides enrichment data across 7 categories including lifecycle, thermal, environmental, platform.
Last verified: April 4, 2026
Key Facts
| Manufacturer | Juniper Networks |
|---|---|
| Model | EX4000-12MP |
| Part Number | EX4000-12MP |
| Type | Device Type |
| Form Factor | 1U, half-depth |
| Airflow | passive |
| Weight | 3.15 kg |
| Interfaces | 17 ports |
| Source | Community DTL |
| Enrichment | 7 categories available |
Specifications
Interfaces (17)
| Name | Type | Mgmt Only | Label |
|---|---|---|---|
| me0 | 1000base-t | true | |
| mge-0/0/0 | 2.5gbase-t | ||
| mge-0/0/1 | 2.5gbase-t | ||
| mge-0/0/2 | 2.5gbase-t | ||
| mge-0/0/3 | 2.5gbase-t | ||
| ge-0/0/4 | 1000base-t | ||
| ge-0/0/5 | 1000base-t | ||
| ge-0/0/6 | 1000base-t | ||
| ge-0/0/7 | 1000base-t | ||
| ge-0/0/8 | 1000base-t | ||
| ge-0/0/9 | 1000base-t | ||
| ge-0/0/10 | 1000base-t | ||
| ge-0/0/11 | 1000base-t | ||
| xe-0/1/0 | 10gbase-x-sfpp | ||
| xe-0/1/1 | 10gbase-x-sfpp | ||
| xe-0/1/2 | 10gbase-x-sfpp | ||
| xe-0/1/3 | 10gbase-x-sfpp |
Power Ports (1)
| Name | Type | Max Draw (W) | Allocated (W) |
|---|---|---|---|
| PSU0 | iec-60320-c14 | 280 |
Console Ports (1)
| Name | Type |
|---|---|
| Console | rj-45 |
Data Sources & Provenance
| Field | Type | Confidence | Source |
|---|---|---|---|
| lifecycle.ga_date | vendor product page | high | blogs.juniper.net |
| environmental.max_operating_temp_c | vendor datasheet | high | www.juniper.net |
| lifecycle.eol_announced | vendor eol bulletin | high | support.juniper.net |
| lifecycle.eos_date | vendor eol bulletin | high | support.juniper.net |
| lifecycle.last_support_date | vendor eol bulletin | high | support.juniper.net |
| thermal.cooling_type | heuristic | low | ndx-pipeline-classification |
| environmental.min_operating_temp_c | vendor documentation | medium-high | www.juniper.net |
| environmental.operating_humidity_min | vendor documentation | medium-high | www.juniper.net |
| environmental.operating_humidity_max | vendor documentation | medium-high | www.juniper.net |
| environmental.operating_altitude_m | vendor documentation | medium-high | www.juniper.net |
| platform.nos | vendor product page | high | www.juniper.net |
| platform.api_types | heuristic | medium | derived from extension blocks and cli_protocol |
| snmp.vendor_oid_prefix | vendor documentation | high | www.juniper.net |
| netconf.netconf_version | vendor documentation | high | www.juniper.net |
Frequently Asked Questions
What is the Juniper EX4000-12MP?
The Juniper EX4000-12MP is a 1U infrastructure device from Juniper Networks. It features 17 network interfaces. The NDX catalog provides enrichment data across 7 categories including lifecycle, thermal, environmental, platform.
What is the form factor of the Juniper EX4000-12MP?
The Juniper EX4000-12MP is a 1U half-depth device with passive airflow. It weighs 3.15 kg.
How many ports does the Juniper EX4000-12MP have?
The Juniper EX4000-12MP has 17 network interfaces: 9x 1000base-t, 4x 2.5gbase-t, 4x 10gbase-x-sfpp.
What are the power requirements for the Juniper EX4000-12MP?
The Juniper EX4000-12MP has 1 power port (iec-60320-c14). Maximum power draw is 280W.
Is the Juniper EX4000-12MP still supported?
Lifecycle data is available for the Juniper EX4000-12MP in the NDX catalog. Access full lifecycle dates including general availability, end-of-sale, and end-of-support through NetBox Cloud or Enterprise.
What operational data is available for the Juniper EX4000-12MP?
The NDX catalog includes enrichment data for the Juniper EX4000-12MP in the following categories: lifecycle, thermal, environmental, platform, snmp, netconf, imagery. Full enrichment values are available through NetBox Cloud or Enterprise.
How do I add the Juniper EX4000-12MP to NetBox?
You can import the Juniper EX4000-12MP directly into NetBox via the NDX features available in NetBox Cloud and NetBox Enterprise. NetBox Community users may download the YAML type definition and import it manually.
Where does the Juniper EX4000-12MP data come from?
The Juniper EX4000-12MP device type definition originates from the NetBox Community Device Type Library and has been enriched with operational metadata by NetBox Labs.
