Huawei S6730-H28X6CZ-TV2
The Huawei S6730-H28X6CZ-TV2 (02354VCS) is a 1U infrastructure device from Huawei. It features 35 network interfaces. The NDX catalog provides enrichment data across 7 categories including lifecycle, thermal, environmental, operational.
Last verified: April 4, 2026
Key Facts
| Manufacturer | Huawei |
|---|---|
| Model | S6730-H28X6CZ-TV2 |
| Part Number | 02354VCS |
| Type | Device Type |
| Form Factor | 1U, full-depth |
| Airflow | front-to-rear |
| Weight | 7.06 kg |
| Interfaces | 35 ports |
| Source | Community DTL |
| Enrichment | 7 categories available |
Specifications
Interfaces (35)
| Name | Type | Mgmt Only | Label |
|---|---|---|---|
| MEth0/0/0 | 1000base-t | true | |
| 10GE1/0/1 | 10gbase-x-sfpp | ||
| 10GE1/0/2 | 10gbase-x-sfpp | ||
| 10GE1/0/3 | 10gbase-x-sfpp | ||
| 10GE1/0/4 | 10gbase-x-sfpp | ||
| 10GE1/0/5 | 10gbase-x-sfpp | ||
| 10GE1/0/6 | 10gbase-x-sfpp | ||
| 10GE1/0/7 | 10gbase-x-sfpp | ||
| 10GE1/0/8 | 10gbase-x-sfpp | ||
| 10GE1/0/9 | 10gbase-x-sfpp | ||
| 10GE1/0/10 | 10gbase-x-sfpp | ||
| 10GE1/0/11 | 10gbase-x-sfpp | ||
| 10GE1/0/12 | 10gbase-x-sfpp | ||
| 10GE1/0/13 | 10gbase-x-sfpp | ||
| 10GE1/0/14 | 10gbase-x-sfpp | ||
| 10GE1/0/15 | 10gbase-x-sfpp | ||
| 10GE1/0/16 | 10gbase-x-sfpp | ||
| 10GE1/0/17 | 10gbase-x-sfpp | ||
| 10GE1/0/18 | 10gbase-x-sfpp | ||
| 10GE1/0/19 | 10gbase-x-sfpp | ||
| 10GE1/0/20 | 10gbase-x-sfpp | ||
| 10GE1/0/21 | 10gbase-x-sfpp | ||
| 10GE1/0/22 | 10gbase-x-sfpp | ||
| 10GE1/0/23 | 10gbase-x-sfpp | ||
| 10GE1/0/24 | 10gbase-x-sfpp | ||
| 10GE1/0/25 | 10gbase-x-sfpp | ||
| 10GE1/0/26 | 10gbase-x-sfpp | ||
| 10GE1/0/27 | 10gbase-x-sfpp | ||
| 10GE1/0/28 | 10gbase-x-sfpp | ||
| 100GE0/0/1 | 100gbase-x-qsfp28 | ||
| 100GE0/0/2 | 100gbase-x-qsfp28 | ||
| 100GE0/0/3 | 100gbase-x-qsfp28 | ||
| 100GE0/0/4 | 100gbase-x-qsfp28 | ||
| 100GE0/0/5 | 100gbase-x-qsfp28 | ||
| 100GE0/0/6 | 100gbase-x-qsfp28 |
Console Ports (1)
| Name | Type |
|---|---|
| console0 | rj-45 |
Module Bays (3)
| Name | Position | Label |
|---|---|---|
| Network Module | 1 | |
| PSU1 | 1 | |
| PSU2 | 2 |
Data Sources & Provenance
| Field | Type | Confidence | Source |
|---|---|---|---|
| thermal.tdp_watts | vendor product page | medium-high | e.huawei.com |
| environmental.max_operating_temp_c | vendor product page | medium-high | e.huawei.com |
| thermal.cooling_type | vendor product page | medium-high | e.huawei.com |
| lifecycle.ga_date | vendor product page | medium-high | e.huawei.com |
| environmental.min_operating_temp_c | vendor product page | medium-high | e.huawei.com |
| environmental.operating_humidity_min | vendor product page | medium-high | e.huawei.com |
| environmental.operating_humidity_max | vendor product page | medium-high | e.huawei.com |
| environmental.operating_altitude_m | vendor product page | medium-high | e.huawei.com |
| operational.typical_power_draw_watts | vendor product page | medium-high | e.huawei.com |
| operational.max_power_draw_watts | vendor product page | medium-high | e.huawei.com |
| operational.noise_level_dba | vendor product page | medium-high | e.huawei.com |
| platform.nos | vendor product page | high | e.huawei.com |
| platform.api_types | heuristic | medium | derived from extension blocks and cli_protocol |
| snmp.profile | vendor documentation | medium-high | support.huawei.com |
| snmp.vendor_oid_prefix | vendor documentation | high | support.huawei.com |
Frequently Asked Questions
What is the Huawei S6730-H28X6CZ-TV2?
The Huawei S6730-H28X6CZ-TV2 (02354VCS) is a 1U infrastructure device from Huawei. It features 35 network interfaces. The NDX catalog provides enrichment data across 7 categories including lifecycle, thermal, environmental, operational.
What is the form factor of the Huawei S6730-H28X6CZ-TV2?
The Huawei S6730-H28X6CZ-TV2 is a 1U full-depth device with front-to-rear airflow. It weighs 7.06 kg.
How many ports does the Huawei S6730-H28X6CZ-TV2 have?
The Huawei S6730-H28X6CZ-TV2 has 35 network interfaces: 28x 10gbase-x-sfpp, 6x 100gbase-x-qsfp28, 1x 1000base-t.
Is the Huawei S6730-H28X6CZ-TV2 still supported?
Lifecycle data is available for the Huawei S6730-H28X6CZ-TV2 in the NDX catalog. Access full lifecycle dates including general availability, end-of-sale, and end-of-support through NetBox Cloud or Enterprise.
What operational data is available for the Huawei S6730-H28X6CZ-TV2?
The NDX catalog includes enrichment data for the Huawei S6730-H28X6CZ-TV2 in the following categories: lifecycle, thermal, environmental, operational, platform, snmp, imagery. Full enrichment values are available through NetBox Cloud or Enterprise.
How do I add the Huawei S6730-H28X6CZ-TV2 to NetBox?
You can import the Huawei S6730-H28X6CZ-TV2 directly into NetBox via the NDX features available in NetBox Cloud and NetBox Enterprise. NetBox Community users may download the YAML type definition and import it manually.
Where does the Huawei S6730-H28X6CZ-TV2 data come from?
The Huawei S6730-H28X6CZ-TV2 device type definition originates from the NetBox Community Device Type Library and has been enriched with operational metadata by NetBox Labs.
