HPE Aruba AP-505H
The HPE Aruba AP-505H (AP-505H) is a infrastructure device from Hewlett Packard Enterprise. It features 8 network interfaces. The NDX catalog provides enrichment data across 7 categories including lifecycle, thermal, environmental, operational.
Last verified: April 4, 2026
Key Facts
| Manufacturer | Hewlett Packard Enterprise |
|---|---|
| Model | Aruba AP-505H |
| Part Number | AP-505H |
| Type | Device Type |
| Form Factor | 0U, half-depth |
| Airflow | passive |
| Weight | 360 g |
| Interfaces | 8 ports |
| Source | Community DTL |
| Enrichment | 7 categories available |
Specifications
Interfaces (8)
| Name | Type | Mgmt Only | Label |
|---|---|---|---|
| E0 | 2.5gbase-t | ||
| E1 | 1000base-t | ||
| E2 | 1000base-t | ||
| E3 | 1000base-t | ||
| E4 | 1000base-t | ||
| 5GHz WiFi | ieee802.11ax | ||
| 2.4GHz WiFi | ieee802.11ax | ||
| Bluetooth | ieee802.15.1 |
Power Ports (1)
| Name | Type | Max Draw (W) | Allocated (W) |
|---|---|---|---|
| 48 Vdc | dc-terminal |
Console Ports (1)
| Name | Type |
|---|---|
| Console | usb-micro-b |
Data Sources & Provenance
| Field | Type | Confidence | Source |
|---|---|---|---|
| environmental.max_operating_temp_c | vendor product page | medium-high | airheads.hpe.com |
| lifecycle.ga_date | vendor datasheet | high | www.securewirelessworks.com |
| operational.max_power_draw_watts | vendor product page | medium-high | airheads.hpe.com |
| operational.typical_power_draw_watts | vendor product page | medium-high | airheads.hpe.com |
| thermal.cooling_type | heuristic | low | ndx-pipeline-classification |
| environmental.min_operating_temp_c | vendor datasheet | high | www.securewirelessworks.com |
| environmental.operating_humidity_min | vendor datasheet | high | www.securewirelessworks.com |
| environmental.operating_humidity_max | vendor datasheet | high | www.securewirelessworks.com |
| environmental.operating_altitude_m | vendor datasheet | high | www.securewirelessworks.com |
| platform.nos | vendor documentation | high | www.arubanetworks.com |
| platform.api_types | heuristic | medium | derived from extension blocks and cli_protocol |
| snmp.vendor_oid_prefix | third party | high | www.iana.org |
| snmp.versions | vendor documentation | medium-high | www.arubanetworks.com |
Frequently Asked Questions
What is the HPE Aruba AP-505H?
The HPE Aruba AP-505H (AP-505H) is a infrastructure device from Hewlett Packard Enterprise. It features 8 network interfaces. The NDX catalog provides enrichment data across 7 categories including lifecycle, thermal, environmental, operational.
What is the form factor of the HPE Aruba AP-505H?
The HPE Aruba AP-505H is a non-rackable device (0U).
How many ports does the HPE Aruba AP-505H have?
The HPE Aruba AP-505H has 8 network interfaces: 4x 1000base-t, 2x ieee802.11ax, 1x 2.5gbase-t, 1x ieee802.15.1.
What are the power requirements for the HPE Aruba AP-505H?
The HPE Aruba AP-505H has 1 power port (dc-terminal).
Is the HPE Aruba AP-505H still supported?
Lifecycle data is available for the HPE Aruba AP-505H in the NDX catalog. Access full lifecycle dates including general availability, end-of-sale, and end-of-support through NetBox Cloud or Enterprise.
What operational data is available for the HPE Aruba AP-505H?
The NDX catalog includes enrichment data for the HPE Aruba AP-505H in the following categories: lifecycle, thermal, environmental, operational, platform, snmp, imagery. Full enrichment values are available through NetBox Cloud or Enterprise.
How do I add the HPE Aruba AP-505H to NetBox?
You can import the HPE Aruba AP-505H directly into NetBox via the NDX features available in NetBox Cloud and NetBox Enterprise. NetBox Community users may download the YAML type definition and import it manually.
Where does the HPE Aruba AP-505H data come from?
The HPE Aruba AP-505H device type definition originates from the NetBox Community Device Type Library and has been enriched with operational metadata by NetBox Labs.
