Fortinet FortiGate 400E
The Fortinet FortiGate 400E (FG-400E) is a 1U infrastructure device from Fortinet. It features 34 network interfaces. The NDX catalog provides enrichment data across 7 categories including lifecycle, thermal, environmental, operational.
Last verified: April 4, 2026
Key Facts
| Manufacturer | Fortinet |
|---|---|
| Model | FortiGate 400E |
| Part Number | FG-400E |
| Type | Device Type |
| Form Factor | 1U, half-depth |
| Airflow | side-to-rear |
| Weight | 16.4 lb |
| Interfaces | 34 ports |
| Source | Community DTL |
| Enrichment | 7 categories available |
Specifications
Interfaces (34)
| Name | Type | Mgmt Only | Label |
|---|---|---|---|
| ha | 1000base-t | ||
| mgmt | 1000base-t | true | |
| port1 | 1000base-t | ||
| port2 | 1000base-t | ||
| port3 | 1000base-t | ||
| port4 | 1000base-t | ||
| port5 | 1000base-t | ||
| port6 | 1000base-t | ||
| port7 | 1000base-t | ||
| port8 | 1000base-t | ||
| port9 | 1000base-t | ||
| port10 | 1000base-t | ||
| port11 | 1000base-t | ||
| port12 | 1000base-t | ||
| port13 | 1000base-t | ||
| port14 | 1000base-t | ||
| port15 | 1000base-t | ||
| port16 | 1000base-t | ||
| port17 | 1000base-x-sfp | ||
| port18 | 1000base-x-sfp | ||
| port19 | 1000base-x-sfp | ||
| port20 | 1000base-x-sfp | ||
| port21 | 1000base-x-sfp | ||
| port22 | 1000base-x-sfp | ||
| port23 | 1000base-x-sfp | ||
| port24 | 1000base-x-sfp | ||
| port25 | 1000base-x-sfp | ||
| port26 | 1000base-x-sfp | ||
| port27 | 1000base-x-sfp | ||
| port28 | 1000base-x-sfp | ||
| s1 | 1000base-x-sfp | ||
| s2 | 1000base-x-sfp | ||
| vw1 | 1000base-x-sfp | ||
| vw2 | 1000base-x-sfp |
Console Ports (1)
| Name | Type |
|---|---|
| Console | rj-45 |
Module Bays (2)
| Name | Position | Label |
|---|---|---|
| PSU1 | 1 | |
| PSU2 | 2 |
Data Sources & Provenance
| Field | Type | Confidence | Source |
|---|---|---|---|
| lifecycle.ga_date | vendor datasheet | high | www.fortinet.com |
| thermal.tdp_watts | vendor datasheet | medium-high | www.fortinet.com |
| thermal.cooling_type | vendor datasheet | high | www.fortinet.com |
| environmental.max_operating_temp_c | vendor documentation | high | docs.fortinet.com |
| environmental.min_operating_temp_c | vendor documentation | high | docs.fortinet.com |
| environmental.operating_humidity_min | vendor documentation | high | docs.fortinet.com |
| environmental.operating_humidity_max | vendor documentation | high | docs.fortinet.com |
| environmental.operating_altitude_m | vendor documentation | medium-high | docs.fortinet.com |
| operational.typical_power_draw_watts | vendor datasheet | medium-high | www.fortinet.com |
| operational.max_power_draw_watts | vendor datasheet | medium-high | www.fortinet.com |
| lifecycle.eos_date | vendor eol bulletin | high | support.fortinet.com |
| lifecycle.eosw_date | vendor eol bulletin | high | support.fortinet.com |
| lifecycle.last_support_date | vendor eol bulletin | high | support.fortinet.com |
| snmp.versions | vendor documentation | medium-high | docs.fortinet.com |
| snmp.vendor_oid_prefix | vendor documentation | high | docs.fortinet.com |
| snmp.mibs | vendor documentation | medium-high | docs.fortinet.com |
| snmp.profile | vendor documentation | medium-high | docs.fortinet.com |
| platform.nos | vendor datasheet | high | www.fortinet.com |
| platform.nos_family | vendor datasheet | high | www.fortinet.com |
| platform.api_types | heuristic | medium | derived from extension blocks and cli_protocol |
Frequently Asked Questions
What is the Fortinet FortiGate 400E?
The Fortinet FortiGate 400E (FG-400E) is a 1U infrastructure device from Fortinet. It features 34 network interfaces. The NDX catalog provides enrichment data across 7 categories including lifecycle, thermal, environmental, operational.
What is the form factor of the Fortinet FortiGate 400E?
The Fortinet FortiGate 400E is a 1U half-depth device with side-to-rear airflow. It weighs 16.4 lb.
How many ports does the Fortinet FortiGate 400E have?
The Fortinet FortiGate 400E has 34 network interfaces: 18x 1000base-t, 16x 1000base-x-sfp.
Is the Fortinet FortiGate 400E still supported?
Lifecycle data is available for the Fortinet FortiGate 400E in the NDX catalog. Access full lifecycle dates including general availability, end-of-sale, and end-of-support through NetBox Cloud or Enterprise.
What operational data is available for the Fortinet FortiGate 400E?
The NDX catalog includes enrichment data for the Fortinet FortiGate 400E in the following categories: lifecycle, thermal, environmental, operational, platform, snmp, imagery. Full enrichment values are available through NetBox Cloud or Enterprise.
How do I add the Fortinet FortiGate 400E to NetBox?
You can import the Fortinet FortiGate 400E directly into NetBox via the NDX features available in NetBox Cloud and NetBox Enterprise. NetBox Community users may download the YAML type definition and import it manually.
Where does the Fortinet FortiGate 400E data come from?
The Fortinet FortiGate 400E device type definition originates from the NetBox Community Device Type Library and has been enriched with operational metadata by NetBox Labs.
