Fortinet FortiGate 120G
The Fortinet FortiGate 120G (FG-120G) is a 1U infrastructure device from Fortinet. It features 30 network interfaces. The NDX catalog provides enrichment data across 7 categories including lifecycle, thermal, environmental, operational.
Last verified: April 4, 2026
Key Facts
| Manufacturer | Fortinet |
|---|---|
| Model | FortiGate 120G |
| Part Number | FG-120G |
| Type | Device Type |
| Form Factor | 1U, half-depth |
| Airflow | side-to-rear |
| Weight | 5.52 kg |
| Interfaces | 30 ports |
| Source | Community DTL |
| Enrichment | 7 categories available |
Specifications
Interfaces (30)
| Name | Type | Mgmt Only | Label |
|---|---|---|---|
| ha | 1000base-t | ||
| mgmt | 1000base-t | true | |
| port1 | 1000base-t | ||
| port2 | 1000base-t | ||
| port3 | 1000base-t | ||
| port4 | 1000base-t | ||
| port5 | 1000base-t | ||
| port6 | 1000base-t | ||
| port7 | 1000base-t | ||
| port8 | 1000base-t | ||
| port9 | 1000base-t | ||
| port10 | 1000base-t | ||
| port11 | 1000base-t | ||
| port12 | 1000base-t | ||
| port13 | 1000base-t | ||
| port14 | 1000base-t | ||
| port15 | 1000base-t | ||
| port16 | 1000base-t | ||
| x1 | 10gbase-x-sfpp | ||
| x2 | 10gbase-x-sfpp | ||
| x3 | 10gbase-x-sfpp | ||
| x4 | 10gbase-x-sfpp | ||
| port17 | 1000base-x-sfp | ||
| port18 | 1000base-x-sfp | ||
| port19 | 1000base-x-sfp | ||
| port20 | 1000base-x-sfp | ||
| port21 | 1000base-x-sfp | ||
| port22 | 1000base-x-sfp | ||
| port23 | 1000base-x-sfp | ||
| port24 | 1000base-x-sfp |
Power Ports (2)
| Name | Type | Max Draw (W) | Allocated (W) |
|---|---|---|---|
| PS1 | iec-60320-c14 | 40 | 38 |
| PS2 | iec-60320-c14 | 40 | 38 |
Console Ports (1)
| Name | Type |
|---|---|
| Console | rj-45 |
Data Sources & Provenance
| Field | Type | Confidence | Source |
|---|---|---|---|
| lifecycle.ga_date | vendor datasheet | high | www.fortinet.com |
| thermal.cooling_type | heuristic | low | ndx-pipeline-classification |
| environmental.max_operating_temp_c | vendor datasheet | high | www.fortinet.com |
| environmental.min_operating_temp_c | vendor documentation | high | docs.fortinet.com |
| environmental.operating_humidity_min | vendor documentation | high | docs.fortinet.com |
| environmental.operating_humidity_max | vendor documentation | high | docs.fortinet.com |
| environmental.operating_altitude_m | vendor documentation | high | docs.fortinet.com |
| operational.typical_power_draw_watts | vendor datasheet | high | www.fortinet.com |
| operational.max_power_draw_watts | vendor datasheet | high | www.fortinet.com |
| operational.noise_level_dba | vendor datasheet | high | www.fortinet.com |
| snmp.versions | vendor documentation | medium-high | docs.fortinet.com |
| snmp.vendor_oid_prefix | vendor documentation | medium-high | docs.fortinet.com |
| snmp.mibs | vendor documentation | medium-high | docs.fortinet.com |
| snmp.profile | vendor documentation | medium-high | docs.fortinet.com |
| platform.nos | vendor datasheet | high | www.fortinet.com |
| platform.nos_family | vendor datasheet | high | www.fortinet.com |
| platform.api_types | heuristic | medium | derived from extension blocks and cli_protocol |
Frequently Asked Questions
What is the Fortinet FortiGate 120G?
The Fortinet FortiGate 120G (FG-120G) is a 1U infrastructure device from Fortinet. It features 30 network interfaces. The NDX catalog provides enrichment data across 7 categories including lifecycle, thermal, environmental, operational.
What is the form factor of the Fortinet FortiGate 120G?
The Fortinet FortiGate 120G is a 1U half-depth device with side-to-rear airflow. It weighs 5.52 kg.
How many ports does the Fortinet FortiGate 120G have?
The Fortinet FortiGate 120G has 30 network interfaces: 18x 1000base-t, 8x 1000base-x-sfp, 4x 10gbase-x-sfpp.
What are the power requirements for the Fortinet FortiGate 120G?
The Fortinet FortiGate 120G has 2 power ports (iec-60320-c14, iec-60320-c14). Maximum power draw is 76W, shared across 2 power ports (up to 40W each, 38W in normal operation).
Is the Fortinet FortiGate 120G still supported?
Lifecycle data is available for the Fortinet FortiGate 120G in the NDX catalog. Access full lifecycle dates including general availability, end-of-sale, and end-of-support through NetBox Cloud or Enterprise.
What operational data is available for the Fortinet FortiGate 120G?
The NDX catalog includes enrichment data for the Fortinet FortiGate 120G in the following categories: lifecycle, thermal, environmental, operational, platform, snmp, imagery. Full enrichment values are available through NetBox Cloud or Enterprise.
How do I add the Fortinet FortiGate 120G to NetBox?
You can import the Fortinet FortiGate 120G directly into NetBox via the NDX features available in NetBox Cloud and NetBox Enterprise. NetBox Community users may download the YAML type definition and import it manually.
Where does the Fortinet FortiGate 120G data come from?
The Fortinet FortiGate 120G device type definition originates from the NetBox Community Device Type Library and has been enriched with operational metadata by NetBox Labs.
