Arista CCS-710P-16P
The Arista CCS-710P-16P is a 1U infrastructure device from Arista Networks. It features 18 network interfaces. The NDX catalog provides enrichment data across 8 categories including lifecycle, thermal, environmental, platform.
Last verified: April 4, 2026
Key Facts
| Manufacturer | Arista Networks |
|---|---|
| Model | CCS-710P-16P |
| Part Number | CCS-710P-16P |
| Type | Device Type |
| Form Factor | 1U, half-depth |
| Weight | 5 lb |
| Interfaces | 18 ports |
| Source | Community DTL |
| Enrichment | 8 categories available |
Specifications
Interfaces (18)
| Name | Type | Mgmt Only | Label |
|---|---|---|---|
| Ethernet1 | 1000base-t | ||
| Ethernet2 | 1000base-t | ||
| Ethernet3 | 1000base-t | ||
| Ethernet4 | 1000base-t | ||
| Ethernet5 | 1000base-t | ||
| Ethernet6 | 1000base-t | ||
| Ethernet7 | 1000base-t | ||
| Ethernet8 | 1000base-t | ||
| Ethernet9 | 1000base-t | ||
| Ethernet10 | 1000base-t | ||
| Ethernet11 | 1000base-t | ||
| Ethernet12 | 1000base-t | ||
| Ethernet13 | 5gbase-t | ||
| Ethernet14 | 5gbase-t | ||
| Ethernet15 | 5gbase-t | ||
| Ethernet16 | 5gbase-t | ||
| Ethernet17 | 10gbase-x-sfpp | ||
| Ethernet18 | 10gbase-x-sfpp |
Power Ports (1)
| Name | Type | Max Draw (W) | Allocated (W) |
|---|---|---|---|
| PS1 | dc-terminal | 280 | 229 |
Console Ports (1)
| Name | Type |
|---|---|
| Console | rj-45 |
Data Sources & Provenance
| Field | Type | Confidence | Source |
|---|---|---|---|
| lifecycle.ga_date | vendor datasheet | high | www.arista.com |
| environmental.max_operating_temp_c | vendor datasheet | high | www.arista.com |
| thermal.cooling_type | vendor datasheet | high | www.arista.com |
| platform.nos | vendor product page | high | www.arista.com |
| platform.api_types | heuristic | medium | derived from extension blocks and cli_protocol |
| snmp.vendor_oid_prefix | vendor documentation | high | www.arista.com |
| netconf.netconf_version | vendor documentation | medium-high | www.arista.com |
| gnmi.gnmi_version | vendor documentation | medium-high | www.arista.com |
Frequently Asked Questions
What is the Arista CCS-710P-16P?
The Arista CCS-710P-16P is a 1U infrastructure device from Arista Networks. It features 18 network interfaces. The NDX catalog provides enrichment data across 8 categories including lifecycle, thermal, environmental, platform.
What is the form factor of the Arista CCS-710P-16P?
The Arista CCS-710P-16P is a 1U half-depth device. It weighs 5 lb.
How many ports does the Arista CCS-710P-16P have?
The Arista CCS-710P-16P has 18 network interfaces: 12x 1000base-t, 4x 5gbase-t, 2x 10gbase-x-sfpp.
What are the power requirements for the Arista CCS-710P-16P?
The Arista CCS-710P-16P has 1 power port (dc-terminal). Maximum power draw is 280W.
Is the Arista CCS-710P-16P still supported?
Lifecycle data is available for the Arista CCS-710P-16P in the NDX catalog. Access full lifecycle dates including general availability, end-of-sale, and end-of-support through NetBox Cloud or Enterprise.
What operational data is available for the Arista CCS-710P-16P?
The NDX catalog includes enrichment data for the Arista CCS-710P-16P in the following categories: lifecycle, thermal, environmental, platform, snmp, gnmi, netconf, imagery. Full enrichment values are available through NetBox Cloud or Enterprise.
How do I add the Arista CCS-710P-16P to NetBox?
You can import the Arista CCS-710P-16P directly into NetBox via the NDX features available in NetBox Cloud and NetBox Enterprise. NetBox Community users may download the YAML type definition and import it manually.
Where does the Arista CCS-710P-16P data come from?
The Arista CCS-710P-16P device type definition originates from the NetBox Community Device Type Library and has been enriched with operational metadata by NetBox Labs.
